Omron NX-EC0222 User Manual

7 SSI Input Units
7 - 8
NX-series Position Interface Units User’s Manual (W524)
The functions of the parts of the SSI Input Unit are described below.
Use the guides to connect the Units to each other.
The indicators show the Unit status, counter operation status, external input status, and other informa-
tion.
The terminal block is used to connect the external I/O signals.
The bus connectors connect the Units to each other.
7-4-2 Functions of the Parts
Unit Hookup Guides
Indicators
Terminal Block
NX Bus Connector
