Omron S8VS-24024A -F Series User Manual

S8VS
2
Ordering Information
List of Models
Note: For details on normal stock models, contact your nearest OMRON representative.
Models without Indication Monitor (Standard Models)
*1. The output capacity of the S8VS-01505 is 10 W.
*2. The output capacity of the S8VS-03005 is 20 W.
*3. The range for compliance with EC Directives and safety standards (UL, EN, etc.) is 100 to 240 VAC (85 to 264 VAC).
Models with Indication Monitor (Maintenance Forecast Monitor)
*1. The range for compliance with EC Directives and safety standards (UL, EN, etc.) is 100 to 240 VAC (85 to 264 VAC).
*2. In the Alarm output column, “sinking” indicates an emitter COM and “sourcing” indicates a collector COM.
Models with Indication Monitor (Total Run Time Monitor)
*1. The range for compliance with EC Directives and safety standards (UL, EN, etc.) is 100 to 240 VAC (85 to 264 VAC).
*2. In the Alarm output column, “sinking” indicates an emitter COM and “sourcing” indicates a collector COM.
Note: Refer to pages 24 to 25 for the options that available.
Power ratings Input voltage Output voltage Output current
UL Class 2
Output standards
Model number
(screw terminal block)
Model number
(screwless terminal block)
15 W
100 to 240 VAC
(allowable range:
85 to 264 VAC or
80 to 370 VDC
*3)
5 V 2.0 A Yes S8VS-01505 *1
---
12 V 1.2 A Yes S8VS-01512
24 V 0.65 A Yes S8VS-01524
30 W
5 V 4.0 A Yes S8VS-03005 *2
12 V 2.5 A Yes S8VS-03012
24 V 1.3 A Yes S8VS-03024
60 W
24 V
2.5 A Yes S8VS-06024 S8VS-06024-F
90 W 3.75 A
--- S8VS-09024 S8VS-09024-F
Yes S8VS-09024S S8VS-09024S-F
120 W 5 A --- S8VS-12024 S8VS-12024-F
180 W 7.5 A --- S8VS-18024 S8VS-18024-F
240 W 10 A --- S8VS-24024 S8VS-24024-F
480 W 100 to 240 VAC
20 A
Peak current 30 A
(200 VAC)
--- S8VS-48024 S8VS-48024-F
Power ratings Input voltage
Output
voltage
Output current
Alarm
output *2
UL Class 2
Output standards
Model number
(screw terminal block)
Model number
(screwless terminal block)
60 W
100 to 240
VAC
(allowable
range: 85 to
264 VAC or 80
to 370 VDC
*1)
24 V
2.5 A --- Yes S8VS-06024A S8VS-06024A-F
90 W 3.75 A
Sinking --- S8VS-09024A S8VS-09024A-F
Sinking Yes S8VS-09024AS S8VS-09024AS-F
Sourcing --- S8VS-09024AP S8VS-09024AP-F
Sourcing Yes S8VS-09024APS S8VS-09024APS-F
120 W 5 A
Sinking --- S8VS-12024A S8VS-12024A-F
Sourcing --- S8VS-12024AP S8VS-12024AP-F
180 W 7.5 A
Sinking --- S8VS-18024A S8VS-18024A-F
Sourcing --- S8VS-18024AP S8VS-18024AP-F
240 W 10 A
Sinking --- S8VS-24024A S8VS-24024A-F
Sourcing --- S8VS-24024AP S8VS-24024AP-F
480 W
100 to 240
VAC
20 A
Peak current 30 A
(200 VAC)
Sinking/
sourcing
--- S8VS-48024A S8VS-48024A-F
Power ratings Input voltage
Output
voltage
Output current
Alarm
output *2
UL Class 2
Output standards
Model number
(screw terminal block)
Model number
(screwless terminal block)
60 W
100 to 240
VAC
(allowable
range: 85 to
264 VAC or 80
to 370 VDC)
*1
24 V
2.5 A --- Yes S8VS-06024B S8VS-06024B-F
90 W 3.75 A
--- --- S8VS-09024BE S8VS-09024BE-F
--- Yes S8VS-09024BES S8VS-09024BES-F
Sinking --- S8VS-09024B S8VS-09024B-F
Sinking Yes S8VS-09024BS S8VS-09024BS-F
Sourcing --- S8VS-09024BP S8VS-09024BP-F
Sourcing Yes S8VS-09024BPS S8VS-09024BPS-F
120 W 5 A
--- --- S8VS-12024BE S8VS-12024BE-F
Sinking --- S8VS-12024B S8VS-12024B-F
Sourcing --- S8VS-12024BP S8VS-12024BP-F
180 W 7.5 A
--- --- S8VS-18024BE S8VS-18024BE-F
Sinking --- S8VS-18024B S8VS-18024B-F
Sourcing --- S8VS-18024BP S8VS-18024BP-F
240 W 10 A
--- --- S8VS-24024BE S8VS-24024BE-F
Sinking --- S8VS-24024B S8VS-24024B-F
Sourcing --- S8VS-24024BP S8VS-24024BP-F
480 W
100 to 240
VAC
20 A
Peak current 30 A
(200 VAC)
Sinking/
sourcing
--- S8VS-48024B S8VS-48024B-F
