Omron STC-HD213 Series User Manual

No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
’
s Guide
12/94
4.3 Mechanical Specifications
STC-HD213DV / STC-HD213DV-CS / STC-HD213DVN / STC-HD213DVN-CS
(*1) Excluding connectors
(*2) Recommend lens: More than F2.8 (Close side)
(*3) Please uses 2.1 mm plug for DC power plug.
762K (Switchcraft) or equivalent plug can be using for lock screw plug.
STC-HD213SDI / STC-HD213SDI-CS / STC-HD213SDIN / STC-HD213SDIN-CS
(*1) Excluding connectors
(*2) Recommend lens: More than F2.8 (Close side)
(*3) Please uses 2.1 mm plug for DC power plug
762K (Switchcraft) or equivalent plug can be using for lock screw plug.
Model Number STC-HD213DV / STC-HD213DVN STC-HD213DV-CS / STC-HD213DVN-CS
Dimensions 40 (W) x 40 (H) x 48.9 (D) mm (*1) 40 (W) x 40 (H) x 43.9 (D) mm (*1)
Optical Filter IR cut filter with OPLF
Optical Center Accuracy
Positional accuracy in Horizontal and Vertical directions: +/- 0.3 mm
Rotational accuracy of Horizontal and Vertical: +/- 1.5 deg.
Material Aluminum alloy (AC)
Lens Mount (*2) C Mount CS Mount
Connectors
Video Output Connector: HDMI Connector
Power Input Connector: DC power jack [PC721A (Switchcraft)](*3)
Remote Control / UART Communication Connector: 3.5Φ Stereo Jack
Camera Mount Screws
Two 1/4” Tripod screw holes: (One on top and bottom plate)
Eight M4 screws holes: (Four on top and bottom plate)
Weight Approximately 129 g Approximately 121 g
Model Number STC-HD213SDI / STC-HD213SDIN STC-HD213SDI-CS / STC-HD213SDIN-CS
Dimensions 40 (W) x 40 (H) x 48.9 (D) mm (*1) 40 (W) x 40 (H) x 43.9 (D) mm (*1)
Optical Filter IR cut filter with OPLF
Material Aluminum alloy (AC)
Lens Mount (*2) C Mount CS Mount
Connectors
Video Output Connector: BNC Connector
Power Input Connector: DC power jack [PC721A (Switchcraft)] (*3)
Remote Control / UART Communication Connector: 3.5Φ Stereo Jack
Camera Mount Screws
Two 1/4” Tripod screw holes: (One on top and bottom plate)
Eight M4 screws holes: (Four on top and bottom plate)
Weight Approximately 138 g Approximately 130 g

Omron STC-HD213 Series Specifications

General

Brand	Omron
Model	STC-HD213 Series
Category	Digital Camera
Language	English
