No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
34/94
7 Control Software User’s Guide
7.1 System Requirements
+12V DC Power Supply: UN310-1210
Communication Tool (Communicate through USB port on PC): JIG-USB-HD
Control Software: JTBCtrl
7.2 Basic Operating Procedure
Connects the power supply with camera, and connect Communication Tool with PC via USB cable
after installing JTBCtrl, control software can be launched from JTACtrl.exe.
Select the COM port number through Comm(C) => Port Setting
Click Read All to read all of register values from camera.
All of camera setting can be configurable through control software.
To Next Page
