No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
92/94
2 Byte consecutive Command
Note: The data have to send as follow order D15-D8, D7-D0.
Function D15
D14
D13
D12
D11
D10
D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
Display Character
Control Command
1 1 RV
R G B BL 0 C7 C6 C5 C4 C3 C2 C1 C0
Display Character Control Command
Sets the writing character data, character color, blink data into Video RAM address.
This command is 2 Byte consecutive command, if more than 2 consecutive character writing are required, just send only lower
8bits (C7 to C0). The write address will be increased automatically.
When character control finishing, it is necessary to send 0xFF (End code of 2 Byte consecutive command).
RV: Reverse character color (0: OFF, 1: ON）
RGB: Character color (0: Black, 1: Blue, 2: Green, 3: Cyan, 4: Red, 5: Magenta, 6: Yellow, 7: White)
BL: Character blinks (0: No blinking, 1: Blinking)
C7-C0: Character code (please refer to the Character table as below)
C7 - C0 Character C7 - C0 Character C7 - C0 Character C7 - C0 Character
000 sp 019 9 032 R 04B k
001 ! 01A : 033 S 04C l
002 “ 01B ; 034 T 04D m
003 # 01C < 035 U 04E n
004 $ 01D = 036 V 04F o
005 % 01E > 037 W 050 p
006 & 01F ? 038 X 051 q
007 ‘ 020 > fill 039 Y 052 r
008 ( 021 A 03A Z 053 s
009 ) 022 B 03B [ 054 t
00A * 023 C 03C ¥ 055 u
00B + 024 D 03D ] 056 v
00C , 025 E 03E < fill 057 w
00D - 026 F 03F △ 058 x
00E . 027 G 040 ▽ 059 y
00F / 028 H 041 a 05A z
010 0 029 I 042 b 05B ・
011 1 02A J 043 c 05C ・・
012 2 02B K 044 d 05D ・・・
013 3 02C L 045 e 05E ～
014 4 02D M 046 f 05F ◆
015 5 02E N 047 g 060 ×
016 6 02F O 048 h 061 ÷
017 7 030 P 049 i 0FF 2 byte
control finish
018 8 031 Q 04A j
To Next Page
