Onkyo A-9110 User Manual

18
Operaciones básicas
(valor predeterminado). Pulse DIRECT para apagar el
indicador DIRECT antes de operar.
1. Gire el mando -/+ TREBLE para mejorar o moderar los
agudos.
BALANCE (solo la unidad principal)
1. Encienda el controlador BALANCE L/R de la unidad
principal para ajustar el balance de los sonidos emitidos
por los altavoces derecho e izquierdo.
SN29403405_A-9110_Es_1806XX.book 18 ページ ２０１８年７月５日 木曜日 午後２時３４分

Onkyo A-9110 Specifications

General

Output level	4 mV
Amplifier class	-
Frequency range	20 - 20000 Hz
Output impedance	4 Ω
Input sensitivity	200 mV
Audio output channels	2.0 channels
Peak power per channel	100 W
Signal-to-Noise Ratio (SNR)	103 dB
Total Harmonic Distortion (THD)	0.05 %
Dynamic power per channel (3 Ohm)	220 W
Dynamic power per channel (4 Ohm)	190 W
Dynamic power per channel (8 Ohm)	110 W
DC-in jack	Yes
Audio (L/R) in	4
Audio (L/R) out	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Banana connector
Purpose	Home
Impedance	47 Ω
Product color	Black
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	220 - 230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	130 W
LED indicators	Status
Package weight	9000 g

Weight and Dimensions

Depth	330 mm
Width	435 mm
Height	129 mm
Weight	7000 g
