Onkyo HT-S680 User Manual

28
Connecting Your Components—Continued
•With the basic connection, you can listen to or record audio from the video source.
•To enjoy Dolby and DTS listening modes, use connection or . (Use and or and for recording.)
Connecting a Satellite, Cable, Set-top box, or Other Video Source
Connection HT-R430 Signal flow Video source Picture quality
S VIDEO VIDEO 2 IN
⇐
S-Video output Better
VIDEO VIDEO 2 IN
⇐
Composite video output Standard
S VIDEO OUT
VIDEO OUT
VIDEO 2
IN
IN
VIDEO
S VIDEO
VIDEO 2
Step 1: Video Connection
Choose a connection type ( or
) that matches the video source, and then make the connection.
A B
A
B
Satellite, cable,
set-top box, etc.
The TV must be connected to
the AV receiver with the
same type of connection.
A
B
Connection HT-R430 Signal flow Video source
VIDEO 2 IN L/R
⇐
Analog audio L/R output
DIGITAL IN COAXIAL
⇐
Digital coaxial output
DIGITAL IN OPTICAL
⇐
Digital optical output
L
R
VIDEO 2
IN
L
R
AUDIO
OUT
OPTICAL
OPTICAL
OUT
DIGITAL IN
COAXIAL
COAXIAL
OUT
Step 2: Audio Connection
Choose a connection type ( , , or ) that matches the video source, and then make the connection.
a b c
a
b
c
Satellite, cable,
set-top box, etc.
Connect one
or the other
a
b c a b
a
c
a
b
c
