54
Troubleshooting—Continued
The sound changes when I connect my head-
phones?
• When a pair of headphones is connected, the listening
mode is set to Stereo, unless it’s already set to Stereo,
Mono, Direct.
How do I change the language of a multiplex
source?
• Use the “Multiplex” setting on the “4. Audio Adjust”
menu to select Main or Sub (page 44).
The functions don’t work?
•To use , you must make an connection and an
analog audio connection (RCA) between the compo-
nent and AV receiver, even if they are connected digi-
tally (page 31).
Specification
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
Others
The AV receiver contains a microcomputer for signal pro-
cessing and control functions. In very rare situations,
severe interference, noise from an external source, or
static electricity may cause it to lockup. In the unlikely
event that this happens, unplug the power cord from the
wall outlet, wait at least five seconds, and then plug it
back in again.
Onkyo is not responsible for damages (such as CD
rental fees) due to unsuccessful recordings caused by
the unit’s malfunction. Before you record important
data, make sure that the material will be recorded cor-
rectly.
To reset the AV receiver to its factory defaults, turn
it on and, while holding down the [VIDEO 1/VCR]
button, press the [STANDBY/ON] button. “Clear”
will appear on the display and the AV receiver will
enter Standby mode.
Before disconnecting the power cord from the wall out-
let, set the AV receiver to Standby.
Power Output
2 channel driven: 100 W + 100 W (8Ω, 1kHz, FTC)
Dynamic Power 210 W + 210 W (3Ω, Front)
155 W + 155 W (4Ω, Front)
105 W + 105 W (8Ω, Front)
THD (Total Harmonic
Distortion) 0.08% (Power Rated)
Damping Factor 60 (Front, 1kHz, 8Ω)
Input Sensitivity and
Impedance 200 mV/ 47 kΩ (LINE)
Output Level and
Impedance 200 mV/ 470 Ω (REC OUT)
Frequency Response 10 Hz–100 kHz/ +1 dB-3 dB (Direct
mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 8Ω– 16Ω
Input Sensitivity/Output
Level and Impedance 1 Vp-p /75Ω (Component and S-Video Y)
0.28 Vp-p /75Ω (S-Video C)
1 Vp-p/75Ω (Composite)
Tuning Frequency
Range North American: 87.5 MHz– 107.9 MHz
Others: 87.5 MHz– 108.0 MHz
Usable Sensitivity Stereo:17.2 dBf 2 µV(75Ω IHF)
Mono: 11.2 dBf 1 µV(75Ω IHF)
Signal to Noise Ratio Stereo: 70 dB (IHF-A)
Mono:76 dB (IHF-A)
THD Stereo: 0.3% (1kHz)
Mono:0.2% (1kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 45 dB (1kHz)
Tuning Frequency
Range North American: 530 kHz–1710 kHz
Others: 522 kHz–1611 kHz
530 kHz–1710 kHz
Usable Sensitivity 30 µV
Signal to Noise Ratio 40 dB
THD 0.70%
To Next Page
