HT-R592_C(B)MDC
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List. (B) : Black color model
<MDC> : 120V,Canadian/USA/(Mexico) model
for HT-S5600
: NSP
HT-R592_C(B)MDC
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
Q6050 TR 2SC5198-O 1 2203063
Q6050 or TR 2SC4468-O ( 1) 2202523
Q6050 or TR 2SC4468-P ( 1) 2202526
Q6050 or TR 2SC5198-R ( 1) 2203062
Q6051 TR 2SC5198-O 1 2203063
Q6051 or TR 2SC4468-O ( 1) 2202523
Q6051 or TR 2SC4468-P ( 1) 2202526
Q6051 or TR 2SC5198-R ( 1) 2203062
Q6052 TR 2SC5198-O 1 2203063
Q6052 or TR 2SC4468-O ( 1) 2202523
Q6052 or TR 2SC4468-P ( 1) 2202526
Q6052 or TR 2SC5198-R ( 1) 2203062
Q6053 TR 2SC5198-O 1 2203063
Q6053 or TR 2SC4468-O ( 1) 2202523
Q6053 or TR 2SC4468-P ( 1) 2202526
Q6053 or TR 2SC5198-R ( 1) 2203062
Q6054 TR 2SC5198-O 1 2203063
Q6054 or TR 2SC4468-O ( 1) 2202523
Q6054 or TR 2SC4468-P ( 1) 2202526
Q6054 or TR 2SC5198-R ( 1) 2203062
Q6055 TR 2SC5198-O 1 2203063
Q6055 or TR 2SC4468-O ( 1) 2202523
Q6055 or TR 2SC4468-P ( 1) 2202526
Q6055 or TR 2SC5198-R ( 1) 2203062
Q6056 TR 2SC5198-O 1 2203063
Q6056 or TR 2SC4468-O ( 1) 2202523
Q6056 or TR 2SC4468-P ( 1) 2202526
Q6056 or TR 2SC5198-R ( 1) 2203062
Q6060 TR 2SA1941-O 1 2203053
Q6060 or TR 2SA1695-O ( 1) 2202513
Q6060 or TR 2SA1695-P ( 1) 2202516
Q6060 or TR 2SA1941-R ( 1) 2203052
Q6061 TR 2SA1941-O 1 2203053
Q6061 or TR 2SA1695-O ( 1) 2202513
Q6061 or TR 2SA1695-P ( 1) 2202516
Q6061 or TR 2SA1941-R ( 1) 2203052
Q6062 TR 2SA1941-O 1 2203053
Q6062 or TR 2SA1695-O ( 1) 2202513
Q6062 or TR 2SA1695-P ( 1) 2202516
Q6062 or TR 2SA1941-R ( 1) 2203052
Q6063 TR 2SA1941-O 1 2203053
Q6063 or TR 2SA1695-O ( 1) 2202513
Q6063 or TR 2SA1695-P ( 1) 2202516
Q6063 or TR 2SA1941-R ( 1) 2203052
Q6064 TR 2SA1941-O 1 2203053
Q6064 or TR 2SA1695-O ( 1) 2202513
Q6064 or TR 2SA1695-P ( 1) 2202516
Q6064 or TR 2SA1941-R ( 1) 2203052
Q6065 TR 2SA1941-O 1 2203053
Q6065 or TR 2SA1695-O ( 1) 2202513
Q6065 or TR 2SA1695-P ( 1) 2202516
Q6065 or TR 2SA1941-R ( 1) 2203052
Q6066 TR 2SA1941-O 1 2203053
Q6066 or TR 2SA1695-O ( 1) 2202513
Q6066 or TR 2SA1695-P ( 1) 2202516
Q6066 or TR 2SA1941-R ( 1) 2203052
[CHASSIS SCREW]
A003 BOTTOM LEG phi48(313) 4 27175472
A005 CUSHION (ZUL) phi20 x phi8 4 28141900
A099 LABEL (SP)609 1 29391541
A101 REAR PANEL HTR592DC 1 27124483A N
[CABINET]
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
