Onkyo RC-863M User Manual

2/31 PAGE
A201 F PANEL HTR592(B)DC 1 27213637B N
A202 CLEAR PLT HTR492(B)D 1 28192399 N
A205 BADGE 1 28135317
A211 KNOB (TONE)(B) 1 28326912
A212 KNOB (INP)(B) 1 28326908B
A213 KNOB (SEL) 1 28326906A
A214 KNOB (INP-LR)(B) 2 28326910B
A225 KNOB (STBY)(B) 1 28326904
A227 KNOB (CUR) 1 28326907B
A701 KNOB (VOL)AS(B) 1 28326914
A709 COVER (B) (Bent) 1 28210089A
A709 COVER (B) (Not Bent) 1 28210089AZ
A721 LABEL HOOKUP-ONKYO 1 29363194
A723 LABEL (COVER) 1 29390767
[TRANS COIL]
T901 P TRANS NPT-1629D 1 2302067 !
[SW TRM]
F6401 FUSE 10A-UL/T-233 1 252330GR !
F6401 or FUSE 10A-T/UL-ST2 ( 1) 252333GR !
F6402 FUSE 10A-UL/T-233 1 252330GR !
F6402 or FUSE 10A-T/UL-ST2 ( 1) 252333GR !
F901 FUSE 8A-UL/T-233 1 252329GR !
F901 or FUSE 8A-T/UL-ST2 ( 1) 252261GR !
P701 FFC NCFC5-232212 1 2045232212
P8001 FFC NCFC5-291022 1 2045291022
P901 AC CORD AS-UC-2 1 253368AYUN !
P901 or AC CORD AS-UC-2 ( 1) 253368BLTK !
[TUNER UNIT]
U001 U0010, U0011, U0012, U0014 BAAF-1310-1C * (Parent) 1 1B288510-1C MDC
U0010 AUDIO(AMP/ASP) PC BOARD AS BAAF-1310-1C (Child) 1 1B2885310-1C
U0011 THERMAL SENSOR PC BOARD AS BAETC-1311-1C (Child) 1 1B2885311-1C
U0012 FIX(SENSOR) PC BOARD AS BAETC-1312-1C (Child) 1 1B2885312-1C
U0014 TERMINAL(TRANS.) PC BOARD AS BAETC-1314-1C (Child) 1 1B2885314-1C
U003 U0030, U0031 BACLA-1318-1A * (Parent) 1 1B288518-1A MDC
U0030 AMP(CLASS A) PC BOARD AS BACLA-1318-1A (Child) 1 1B2885318-1A
U0031 FIX(FFC) PC BOARD AS BAETC-1319-1A (Child) 1 1B2885319-1A
U004 U0040, U0041 BATRM-1089-2C * (Parent) 1 1B288589-2C MDC
U0040 TERMINAL(SPEAKER) PC BOARD AS BATRM-1089-2C (Child) 1 1B2885089-2C
U0041 TERMINAL(DIGITAL) PC BOARD AS BAETC-1091-2C (Child) 1 1B2885091-2C
U006 U0060, U0061, U0062, U0063, U0064, U0065 BADIS-1370-1C * (Parent) 1 1B288570-1C MDC
U0060 DISPLAY PC BOARD AS BADIS-1370-1C (Child) 1 1B2885370-1C
U0061 SWITCH/LED PC BOARD AS BADIS-1371-1C (Child) 1 1B2885371-1C
U0062 VIDEO PC BOARD AS BAVD-1372-1C (Child) 1 1B2885372-1C
U0063 POWER SUPPLY(PRI) PC BOARD AS BAETC-1373-1C (Child) 1 1B2885373-1C
U0064 PHONE JACK PC BOARD AS BAETC-1374-1C (Child) 1 1B2885374-1C
U0065 CONNECTOR(FFC-SOCKET) PC BOARD AS BAETC-1379-1C (Child) 1 1B2885379-1C
U008 U0080 BAHDM-1337-1A * (Parent) 1 1B288537-1A MDC
U0080 PROCESSING PC BOARD AS BAHDM-1337-1A (Child) 1 1B2885337-1A
U009 TUNER UNIT FAEH08-W01 1 240169A
HT-R592_C(B)MDC
PACKING PROCEDURES PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[PACKING]
A801 PAD (AS)HTR390 1 29092582A
A801A PAD (L)HTR390 { 1} 29092583A
A801B PAD (R)HTR390 { 1} 29092584A
A803 POLY BAG w850xd650 1 29100245
A805 TAPE (SEROHAN)NITTO NO.29 1 29110149
A807 SHEET T0.5 x 600 x 500 1 29096097
A809 TAPE (SEROHAN)NITTO NO.29 1 29110149
A812 POLY BAG w250xd350 1 29100250A
A813 TAPE (SEROHAN)NITTO NO.29 1 29110149
A814A LABEL (DES)HTR592BMDC { 1} 29392244 N
HT-R592_C(B)MDC
PC BOARD PARTS LIST
U001 BAAF-1310-1C
: NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D4173 ZENER D DZ2J068M0L 1 224760680R2

Onkyo RC-863M Specifications

General

Brand	Onkyo
Model	RC-863M
Category	Receiver
Language	English
