General Specifications
Network AV Receiver (HT-L05)
Amplifier (Audio) section
Rated Output Power (FTC)
Surround Mode Output Power ( ＊ )
(4 ohms, 1 kHz THD 1%) 50 W per channel
＊ Reference output for each speakers.
Depending on the source and the listening mode settings, there
may be no sound output.
Input Sensitivity and Impedance (1 kHz 50 W/4 Ω)
200 mV/47 kΩ (LINE (Unbalance))
Tone Control Characteristics
n10 dB, 90 Hz (BASS)
n10 dB, 7.5 kHz (TREBLE)
Signal to Noise Ratio
80 dB (IHF-A, LINE IN, SP OUT)
Speaker Impedance
4 Ω
Headphone Output Impedance
102 Ω
Headphone Rated Output
85 mW (32 Ω, 1 kHz, 10% THD)
Tuner Section
FM Tuning Frequency Range
87.5 MHz - 107.9 MHz
Preset Channel
40
Network Section
Ethernet LAN
10BASE-T/100BASE-TX
Wireless LAN
IEEE 802.11 a/b/g/n standard
(Wi-Fi
®
standard)
5 GHz/2.4 GHz band
BLUETOOTH Section
Communication system
BLUETOOTH Specification version 4.1+LE
Frequency band
2.4 GHz band
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profiles
A2DP 1.2
AVRCP 1.3
HOGP-Host (Client)
HOGP-HID Device (Server)
HID Service (HIDS)
Supported Codecs
SBC
AAC
Transmission range (A2DP)
20 Hz - 20 kHz (Sampling frequency 44.1 kHz)
Maximum communication range
Line of sight approx. 15 m ( ＊ )
＊ The actual range will vary depending on factors such as obstacles
between devices, magnetic fields around a microwave oven, static
electricity, cordless phone, reception sensitivity, antenna’s
performance, operating system, software application, etc.
General
Power Supply
AC 100 - 240 V, 50/60 Hz
Power Consumption
60 W
0.2 W (Stand-by)
16 W (No-sound)
2 W (HDMI Standby Through)
2 W (Network Standby)
Dimensions (W k H k D)
435 mm k 70 mm k 325.5 mm
17-1/8" k 2-3/4" k 12-13/16"
Weight
4 kg (8.8 lbs)
HDMI
Input
IN1 (BD/DVD, HDCP2.2), IN2 (CBL/SAT, HDCP2.2), IN3
(STRM BOX, HDCP2.2), IN4 (GAME, HDCP2.2)
Output
OUT (HDCP2.2)
Supported
Deep Color, x.v.Color
TM
, LipSync, Audio Return Channel,
3D, 4K 60Hz, CEC, Extended Colorimetry (sYCC601,
Adobe RGB, Adobe YCC601), Content Type, HDR
Audio Format
Dolby Atmos, Dolby TrueHD, Dolby Digital, Dolby Digital
Plus, DTS, DTS:X, DTS-HD Master Audio, DTS-HD High
Resolution Audio, DTS 96/24, DTS-HD Express, DSD,
PCM
Maximum Video Resolution
4k 60 Hz (YCbCr 4:4:4)
Audio Inputs
Digital
OPTICAL (TV)
Analog
1 (CD)
Audio Outputs
Speaker Outputs
Special 16-pin connector (FRONT L/R, CENTER,
HEIGHT L/R)
Phones
PHONES (Front, φ3.5 mm)
Others
USB: 1 (Front, Ver.2.0, 5 V/1 A)
Ethernet: 1
Setup Mic: 1
