Onkyo T-4030 User Manual

En-6
Supplied Accessories
Make sure you have the following accessories:
Remote controller (RC-852T) and two batteries (AAA/R03)
Audio cable
R cable
To use R, T-4030 must be connected with an R cable.
DAB antenna
* In catalogs and on packaging, the letter at the end of the product
name indicates the color. Specifications and operation are the
same regardless of color.
Notes:
• If the remote controller doesn’t work reliably, try
replacing the batteries.
• Don’t mix new and old batteries or different types of
batteries.
• If you intend not to use the remote controller for a long
time, remove the batteries to prevent damage from
leakage or corrosion.
• Expired batteries should be removed as soon as
possible to prevent damage from leakage or corrosion.
When using the remote controller, point it toward the
tuner’s remote control sensor, as shown below.
Installing the Batteries
Aiming the Remote Controller
T-4030
30°
30°
Remote control sensor
Approx. 5 m (16 ft.)

Onkyo T-4030 Specifications

General

Power requirements	230V, 50 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	8 W
Purpose	Home
DAB tuner	DAB+
RDS features	PS, PTY, RT
FM band range	87.5 - 108 MHz
Product color	Silver
Frequency range	20 - 15000 Hz
Radio Data System (RDS)	Yes
Preset stations quantity	40
Total Harmonic Distortion (THD)	1 %
Line outputs (RCA)	2

Weight and Dimensions

Depth	307 mm
Width	435 mm
Height	101.5 mm
Weight	4900 g
