Onkyo TX-8555 User Manual

22
Turning On the Receiver
For the TAPE and VCR/DVR buttons, the input display
name can be changed in the sequence as shown below.
When the input display name has been changed for one
of the buttons below, the display name for the other
button cannot be changed.
• TAPE button : TAPE→MD→CDR→DOCK
• VCR/DVR button : VCR/DVR→DOCK
ON/STANDBY
STANDBY indicator
ON/STANDBY
Turning On and Standby
1
Press the [ON/STANDBY] button.
Alternatively, press the remote
controller’s [ON/STANDBY]
button.
The receiver comes on, the display
lights up, and the STANDBY indicator
goes off.
To turn the receiver off, press the
[ON/STANDBY] button, or press the
remote controller’s [ON/STANDBY]
button. The receiver will enter Standby
mode. To prevent any loud surprises
when you next turn on the receiver,
always turn down the volume before
you turn it off.
or
Receiver
Remote
controller
Changing the Input Display
1
Press the appropriate input
selector button.
The selected input name appears in the
display.
2
Press and hold down the input
selector button selected in the
Step 1 above for approximately 3
seconds to change the display
name.
or

Onkyo TX-8555 Specifications

General

Impedance	4 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.08 %
Output power	110 W
Package depth	560 mm
Package width	419 mm
Package height	250 mm
Dimensions (WxDxH)	435 x 149 x 340 mm
Power requirements	AC 230-240 V, 50 Hz
Output power description	90 W/Ch
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Product color	Black
Package weight	9500 g

Weight and Dimensions

Weight	7500 g
