Onkyo TX-NR696-S User Manual

119
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Setting Item Default Value Setting Details
Zone 2 Lineout Zone 2 Set an output destination of the audio output from
ZONE 2 LINE OUT/ZONE B LINE OUT jack.
"Zone 2": When connecting a pre-main amplier in
a separate room (ZONE 2)
"Zone B": When connecting a pre-main amplier,
transmitter of wireless headphones, etc. to ZONE B
"Front": When connecting a power amplier
(European, Australian and Asian models)
• This setting is xed to "Zone 2" when "Zone
Speaker" is set to "Zone 2".
Bi-Amp No Set whether the front speakers are bi-amp
connected.
"No": When front speakers are not bi-amp
connected
"Yes": When front speakers are bi-amp connected
• This setting is xed to "No" if "Zone Speaker" is
set to "Zone 2".
• This setting cannot be selected when surround
back speakers or height speakers are installed.
Speaker
Impedance
6 ohms or above Set the impedance (Ω) of the connected speakers.
"4ohms": When any of the connected speakers
have 4 Ω or more to less than 6 Ω impedance
"6 ohms or above": When all the connected
speakers have an impedance of 6 Ω or more
• For impedance, check the indications on the
back of the speakers or their instruction manual.
 2. Crossover
Change the settings of crossover frequencies.
• As for the THX-certied speakers, the following settings are recommended.
– Crossover frequency → "80 Hz(THX)"
– "LPF of LFE" → "80 Hz"
– "Double Bass" → "O󰀨"
Setting Item Default Value Setting Details
Front 80 Hz (THX) Select the crossover frequency from "40 Hz" to
"200 Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
• If "Conguration" - "Subwoofer" is set to "No",
"Front" is xed to "Full Band", and the low
pitched range of the other channels is output
from the front speakers. Refer to the instruction
manual of your speakers to make the setting.
Center 80 Hz (THX) Select the crossover frequency from "40 Hz" to
"200 Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
• "Full Band" can be selected only when "Front" is
set to "Full Band".
• If the item cannot be selected even though
connection is correct, check if the setting in
"Conguration" - "Speaker Channels" matches
the number of connected channels.
Height 80 Hz (THX) Select the crossover frequency from "40 Hz" to
"200 Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
• "Full Band" can be selected only when "Front" is
set to "Full Band".
• If the item cannot be selected even though
connection is correct, check if the setting in
"Conguration" - "Speaker Channels" matches
the number of connected channels.

Onkyo TX-NR696-S Specifications

General

THX-certified	THX Select
3D	Yes
Supported graphics resolutions	3840 x 2160
HDCP version	2.2
Apple docking	-
Product color	Silver
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Internet radio services supported	Deezer, Spotify, Tidal, TuneIn
Receiver type	Surround
Output impedance	470 Ω
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	240 W
Dynamic power per channel (4 Ohm)	210 W
Dynamic power per channel (8 Ohm)	120 W
Power output per channel (1KHz@6 Ohm)	175 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio formats supported	AIFF, ALAC, DSD, FLAC, WAV
HDMI in	7
Digital audio optical in	1
Headphone connectivity	6.3 mm
Number of HDMI outputs	2
Phono inputs (RCA)	4
Connectivity technology	Wired & Wireless
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	570 W
Package depth	468 mm
Package width	534 mm
Package height	265 mm
Package weight	12500 g
Optical drive included	No

Weight and Dimensions

Depth	379.5 mm
Width	435 mm
Height	173.5 mm
Weight	10000 g
