Onkyo TX-NR696-S User Manual

112
Setup
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Setup Menu
Menu list
You can congure advanced settings to have a more enjoyable experience with this unit. For operation details, refer to "Menu operations" ( p114).
1. Input/Output
Assign
1. TV Out / OSD Make settings for TV output and On-Screen Displays (OSD) that appear on the TV. p115
2. HDMI Input Change input assignment between the input selectors and HDMI IN jacks.
p116
3. Digital Audio Input Change input assignment between the input selectors and DIGITAL IN COAXIAL/OPTICAL jacks.
p117
4. Analog Audio Input Change input assignment between the input selectors and AUDIO IN jacks.
p118
2. Speaker 1. Conguration Change the settings of connection environment of the speakers.
p118
2. Crossover Change the settings of crossover frequencies.
p119
3. Distance Set the distance from each speaker to the listening position.
p120
4. Level Calibration Adjust the volume level of each speaker.
p121
5. Dolby Enabled
Speaker
Change the settings of Dolby Enabled Speakers.
p121
6. Equalizer Settings You can adjust the output volume of the range for each connected speaker.
p122
7. THX Audio Change the THX Audio settings.
p122
8. Speaker Virtualizer The Speaker Virtualizer function can be switched between On and O󰀨.
p123
3. Audio Adjust 1. Multiplex/Mono Change the settings of multiplex audio playback.
p123
2. Dolby Change the setting of when Dolby signals are input.
p124
3. DTS Change the setting of when DTS signals are input.
p124
4. LFE Level Set the low-frequency e󰀨ect (LFE) level for Dolby Digital series, DTS series, Multichannel PCM,
and DSD signals.
p124
5. Volume Change the Volume settings.
p125

Onkyo TX-NR696-S Specifications

General

THX-certified	THX Select
3D	Yes
Supported graphics resolutions	3840 x 2160
HDCP version	2.2
Apple docking	-
Product color	Silver
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Internet radio services supported	Deezer, Spotify, Tidal, TuneIn
Receiver type	Surround
Output impedance	470 Ω
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	240 W
Dynamic power per channel (4 Ohm)	210 W
Dynamic power per channel (8 Ohm)	120 W
Power output per channel (1KHz@6 Ohm)	175 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio formats supported	AIFF, ALAC, DSD, FLAC, WAV
HDMI in	7
Digital audio optical in	1
Headphone connectivity	6.3 mm
Number of HDMI outputs	2
Phono inputs (RCA)	4
Connectivity technology	Wired & Wireless
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	570 W
Package depth	468 mm
Package width	534 mm
Package height	265 mm
Package weight	12500 g
Optical drive included	No

Weight and Dimensions

Depth	379.5 mm
Width	435 mm
Height	173.5 mm
Weight	10000 g
