Onkyo TX-RZ710 User Manual

61
> Specifications > Settings > Listening Modes > Playback Function > Basic Manual
Troubleshooting | Appendix
Other Functions
Playing Audio and Video from Separate Sources
It is possible to play audio and video from different
sources. For example, you can play audio from the CD
player and video from the BD/DVD player. The procedure
in this case is as follows:
1. Press BD/DVD.
2. Press CD.
3. Start playback on the BD/DVD player and CD player.
Perform the following steps to play the video from
a different source to suit the audio from a NET or
BLUETOOTH input source.
1. Press NET or
to play the audio.
2. Press MODE on the remote controller and the video
input select immediately preceding this operation can
be played.
3. Start play of the video input source.
4. Each press of MODE displays or turns off the video.

Onkyo TX-RZ710 Specifications

General

Impedance	6 Ω
Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	250 W
Dynamic power per channel (4 Ohm)	220 W
Power output per channel (20-20KHz@8 Ohm)	130 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Internet radio	Yes
Supported radio bands	AM, FM
Preset stations quantity	40
Internet radio services supported	Pandora, Spotify, TuneIn
Optical drive included	No
Display	LCD
Audio decoders	DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
RS-232 ports	1
Speakers connectivity type	Clamp terminals
THX-certified	THX Select2 Plus
Package depth	468 mm
Package width	570 mm
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	600 W
Bluetooth version	4.1
HDMI in	8
Headphone connectivity	3.5 mm

Weight and Dimensions

Depth	378 mm
Width	435 mm
Height	288 mm
Weight	10500 g
