SPECIFICATIONS
7-1
SPECIFICATIONS
Model FTN-R FTN-RAM
Detection method Passive infrared
PIR coverage 5 × 1 m (16'5" × 3'3")
Detection length limit 2 m, 5 m (6'7", 16'5")
Detectable speed 0.3 – 1.5 m/s (1' – 4'11"/s)
Sensitivity 2.0°C (at 0.6 m/s) (3.6°F (at 2'/s))
Operation voltage 2.5 – 10 V DC
Power input 3 – 9 V DC (Lithium or Alkali Battery)
Current draw
9 μA (at stand-by)/3 mA
(max.) (at 3 V DC)
10 μA (at stand-by)/3 mA
(max.) (at 3 V DC)
Alarm period 2.0 ±1.0 sec.
Warm-up period Approx. 120 sec. (LED blinks)
Alarm output
N.C./N.O. Selectable-Solid State Switch 10 V DC 0.01 A
(max.)
Trouble output
N.C./N.O. Selectable-Solid State Switch 10 V DC 0.01 A
(max.)
LED indicator
Enable: During DIP switch 1 (WALK TEST MODE) or
DIP switch 4 (LED) ON
Disable: During normal operation
Light/Blink: Warm-up, alarm, masking detection
RF Interference No alarm 10 V/m
Operation temperature -20 – +60°C (-4 – +140°F)
Environment humidity 95% max.
Weatherproof IP55
Mounting Wall (Outdoor, Indoor)
Mounting height 0.8 – 1.2 m (2'7" – 3'11")
Weight 190 g (6.7 oz.)
Accessories
Connector for POWER and ALARM,
connector for TROUBLE, plate nut × 2,
screw (M3 × 10 mm) × 2, screw (3 × 20 mm) × 4,
sponge for transmitter
*Specifications and design are subject to change without prior notice.
