User’ Guide

NAT : Enable

WAN SETUP :

NAT public IP configuration : Automatically

NAT public IP address : 68.101.124.67 Subnet Mask : 255.255.255.0

NAT public Gateway IP address : 68.101.124.1

LAN SETUP :

Sub Ethernet interface IP address 192.168.100.1 subnet-mask 255.255.255.0

DHCP Server Pool Table :

DHCP server support 512 IP, Created 20 IP

Pool Index Begin IP End IP

1 192.168.100.1 192.168.100.21

Provision assigned DNS 68.4.16.25

Provision assigned DNS 68.2.16.30

Provision assigned DNS 68.6.16.30

DHCP server lease time : 1800

IP Mapping Table:

Index Global IP Local IP

1 64.168.39.3 192.168.100.4

¾ nat static ipmapping delete {index/all}

Remove NAT one to one mapping entry from the IP Mapping Table

index: The index number IP Mapping Table (see “show nat config”command )

Port forwarding setting

¾ nat static portmapping add {port }{ private ipaddress} {tcp|udp}

Set NAT/PAT Port forwarding table

Example:

CM>nat static portmapping add 21 192.168.100.23 tcp

CM>show nat config

NAT : Enable

WAN SETUP :

NAT public IP configuration : Manually

Static NAT public IP address : 68.5.203.15 Subnet Mask : 255.255.254.0

Static NAT public Gateway IP address : 68.5.202.1

LAN SETUP :

Ethernet interface IP address 192.168.100.1 subnet-mask 255.255.255.224

NAT DHCP Server Pool Table :

NAT DHCP server support

NAT DHCP server support 512 IP, Created 20 IP

Pool Index Begin IP End IP

Orion 2000 User Manual
