Panasonic CS-Z20TKR User Manual

163
19. Technical Data
Technical data provided are based on the air conditioner running under free frequency.
19.1 Cool Mode Performance Data
Unit setting: Standard piping length, Hi Fan, Cool mode at 16°C
Voltage: 230V/240V
19.1.1 CS-Z20TKR CU-Z20TKR
Indoor (°C) Outdoor DB (°C)
DB WB
5 16 25 30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
19 2238 2084 350 2519 2250 239 2349 2200 317 2199 2119 364 2050 2030 410 1866 1778 451 1682 1541 492
22 2591 1718 279 2775 1828 229 2574 1727 313 2436 1677 362 2295 1619 412 2114 1429 447 1928 1247 481
23
15.7 2047 2025 328 2270 2175 247 2105 2084 320 1985 1965 365 1862 1844 410 1681 1664 454 1502 1487 498
18.4 2201 1646 343 2413 1743 241 2297 1720 318 2183 1670 364 2065 1613 410 1926 1396 451 1778 1188 492
20
13.3 1880 1862 336 2135 2114 252 1939 1920 321 1836 1818 366 1730 1713 409 1438 1423 396 1172 1161 372
15.8 2001 1599 353 2245 1733 246 2092 1667 320 1986 1620 365 1876 1567 410 1732 1376 455 1583 1194 500
(Dry bulb value based on 46% humidity)
19.1.2 CS-Z25TKR CU-Z25TKR
Indoor (°C) Outdoor DB (°C)
DB WB
5 16 25 30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
19 2729 2542 427 3072 2744 291 2864 2682 387 2682 2584 443 2500 2475 500 2276 2169 550 2051 1879 600
22 3160 2096 340 3384 2229 279 3139 2106 382 2971 2045 442 2799 1974 502 2578 1743 545 2351 1520 587
23
15.7 2496 2470 400 2768 2653 301 2568 2542 390 2421 2396 445 2271 2249 500 2050 2029 554 1831 1813 608
18.4 2684 2007 418 2942 2125 294 2801 2097 387 2662 2037 444 2518 1967 501 2349 1702 550 2169 1448 600
20
13.3 2293 2270 410 2604 2578 308 2365 2341 392 2239 2217 446 2110 2089 499 1753 1736 483 1430 1416 454
15.8 2440 1950 431 2738 2113 301 2551 2033 390 2422 1976 445 2288 1911 500 2112 1678 555 1931 1456 610
(Dry bulb value based on 46% humidity)
19.1.3 CS-Z35TKR CU-Z35TKR
Indoor (°C) Outdoor DB (°C)
DB WB
5 16 25 30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
19 3821 3523 683 4301 3803 466 4010 3717 619 3755 3580 710 3500 3430 800 3186 3006 880 2872 2604 961
22 4424 2904 544 4738 3089 447 4394 2919 611 4159 2834 707 3918 2736 803 3609 2415 872 3292 2107 939
23
15.7 3495 3423 640 3876 3676 482 3595 3562 625 3389 3355 713 3180 3148 800 2869 2841 886 2564 2538 973
18.4 3757 2782 669 4119 2945 470 3921 2907 620 3727 2822 710 3525 2726 801 3288 2359 881 3036 2007 960
20
13.3 3210 3178 656 3646 3609 493 3311 3278 627 3135 3103 713 2954 2924 798 2455 2430 772 2002 1982 726
15.8 3416 2702 689 3834 2928 481 3571 2817 624 3391 2738 713 3204 2648 801 2957 2326 888 2703 2018 976
(Dry bulb value based on 46% humidity)

Panasonic CS-Z20TKR Specifications

General

Brand	Panasonic
Model	CS-Z20TKR
Category	Air Conditioner
Language	English
