14.10 Auto Restart Control
 When the power supply is cut off during the operation of air conditioner, the compressor will re-operate within
three to four minutes (there are 10 patterns between 2 minutes 58 seconds and 3 minutes 52 seconds to be
selected randomly) after power supply resumes.
 This type of control is not applicable during ON/OFF Timer setting.
 This control can be omitted by open the circuit of JP1 at indoor unit printed circuit board.
14.11 Indication Panel
LED POWER TIMER iAUTO-X nanoe-G ECONAVI
Color Green Orange Orange Blue Green
Light ON Operation ON Timer Setting ON iAUTO-X Mode ON nanoe-G ON ECONAVI ON
Light OFF Operation OFF Timer Setting OFF iAUTO-X Mode OFF nanoe-G OFF ECONAVI OFF
Note:
 If POWER LED is blinking, the possible operation of the unit are Hot Start, during Deice operation, operation
mode judgment, or ON timer sampling.
 If Timer LED is blinking, there is an abnormality operation occurs.
14.12 nanoe-G Operation
 This operation provides clean air by producing great amount of negative ions and distribute through the
discharge airflow to capture or deactivate molds, bacteria or viruses.
 nanoe-G operation start condition
o During unit running at any operation mode, if nanoe-G operation is activated, combination operation
(operation mode + nanoe-G operation) starts.
o During unit is OFF, if nanoe-G operation is activated, nanoe-G individual operation starts.
 nanoe-G operation stop condition
o When OFF/ON button is pressed to stop the operation.
o When nanoe-G button is pressed.
o When OFF Timer activates.
 nanoe-G operation pause condition
o When indoor fan stop (during deice, odor cut control, thermostat off, etc.). nanoe-G operation resume after
indoor fan restarts.
o When indoor intake temperature  40°C. nanoe-G operation resume after indoor intake temperature < 40°C
continuously for 30 minutes.
 Indoor fan control
o During any operation mode combines with nanoe-G operation, fan speed follows respective operation mode.
However, nanoe-G system enabled when fan speed  500 rpm to ensure proper negative ion distribution,
nanoe-G system disabled when fan speed < 500 rpm.
o During nanoe-G individual operation, only Auto Fan Speed is allowed. Even if Fan Speed button is pressed,
no signal is sent to the unit and no change on remote control display.
 Airflow direction control
o During any operation mode combines with nanoe-G operation, airflow direction follows respective operation
mode.
o During nanoe-G individual operation, only Auto Air Swing is allowed. Even if Air Swing button is pressed, no
signal is sent to the unit and no change on remote control display.
 Timer control
o When ON Timer activates when unit stops, previous operation resumes and restored last saved nanoe-G
operation status.
o When ON Timer activates during any operation, no change on current operation.
o When OFF Timer activates during any operation, all operation stops and the latest nanoe-G operation status
is saved.
