29
7.2 CU-Z42TKR CU-Z50TKR CU-Z60TKR CU-Z71TKR CU-Z80TKR
INDOOR OUTDOOR
INTAKE
TEMP.
SENSOR
PIPE
TEMP.
SENSOR 1
AIR
TEMP.
SENSOR
PIPE
TEMP.
SENSOR
LIQUID
SIDE
2-WAY
VALVE
3-WAY
VALVE
COMPRESSOR
DISCHARGE
MUFFLER
COMPRESSOR
TEMP.
SENSOR
GAS
SIDE
COOLING
HEATING
HEAT EXCHANGER
(EVAPORATOR)
HEAT EXCHANGER
(CONDENSER)
EXPANSION
VALVE
4-WAY VALVE
STRAINER
RECEIVER
(FOR Z42/60/71/80TK
ONLY)
STRAINER
(FOR Z80TK
ONLY)
PIPE
TEMP.
SENSOR 2
(FOR Z80TK ONLY)
Temp. (°C)
Indoor Sensor Outdoor Sensor
Pipe Temp. (k) Intake Air Temp. (k) Pipe Temp. (k) Air Temp. (k) Comp. Temp. (k)
-15 148.40 111.27 35.82 117.11 390.36
5 51.16 38.37 12.41 38.93 129.75
15 31.52 23.64 7.72 23.77 79.22
20 25.02 18.77 6.17 18.81 62.69
25 20.00 15.00 5.00 15.00 50.00
30 16.10 12.07 4.02 12.05 40.18
45 8.71 6.53 2.22 6.52 21.72
