Panasonic KX-NS500 Sales Guide

Cost Saving
IP Networking -Saving Communication Costs-
The adequate IP capacity of the KX-NS500 enables you to combine both IP and legacy trunks according to your needs, to
construct systems that are flexible and cost effective.
Recommended for:
Companies using an IP/ISDN/PSTN network
system.
20
Features and Benefits
Constructing a hybrid system that combines
both legacy and IP lines to further reduce costs.
SIP
Trunk
Head Office
KX-NS500
ISDN/
PSTN

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
