Panasonic KX-NS500 Sales Guide

Simplified Maintenance -Web Maintenance-
44
Installer Office
KX-NS500
Web Maintenance
Public/Private
IP Network
User
Web Console
Fwd/DND, VM greetings, and
e-mail addresses etc…
can be set from a PC
Selling Points
The features described on previous pages can be programmed with a Web based console via an IP
network. Phones and the VM mailbox can also be customised by users via the Web.
 Programming is easy for experienced Panasonic
installers because the programming method is
basically the same as the KX-TDA, KX-TDE, KX-NCP
and KX-TVM.
 No need to install dedicated software on your PC.
 Use an IP network to perform programming from
remote sites.
 A maximum of 1 installer can modify system data at
the same time.
 A maximum of 32 users can access at the same time.

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
