Panasonic KX-NS500 Sales Guide

Cost Saving
IP Networking -Saving Running Costs-
Features and Benefits
No need to change the PBX settings when
phones are moved to another place.
Recommended for:
Companies with a need to change their office
layout on occasion.
Companies which have an LAN network system.
Growing companies
Office
2F
1F
IP proprietary telephones
Simple move
23
By using IP phones as extensions, there is no need to change the settings of the PBX each time the office layout is changed.
KX-NS500

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
