- 119 -
Recording
This mode makes it easy to pick out the subject on which to focus and blurs the
background to make the subject stand out.
Setting the AF area
1 Touch the subject to move the AF area.
AF area can also be moved by pressing the cursor button.
2 Touch [SET].
Note
Quick AF is performed automatically.
Use the functions that are assigned to the cursor button, such as [WHITE BALANCE] (P103),
by assigning them to the menu item of the Quick Menu (P64).
AF area setting screen is displayed by pressing the cursor button. Touch [RESET] to return the
AF area to the center of the screen.
The obtained effects will differ depending on factors such as the distance to the subject and
background, and the type of lens used. For best results, we recommend getting as close as
possible to the subject when taking pictures. (P100)
Flowers outdoors are recorded with natural colors in macro settings. The guide lines are
displayed.
Technique for Flower Mode
We recommend using a tripod and the self-timer.
We recommend setting the flash to [Œ] when you take pictures at close range.
Note
The focus range is different depending on lens used. Refer to About the focus distance
reference mark
on P100 for the focus range.
When a subject is close to the camera, the effective focus range is significantly narrowed.
Therefore, if the distance between the camera and the subject is changed after focusing on the
subject, it may become difficult to focus on it again.
Close-up regions are prioritized when taking pictures, and so time is required to focus if you
take a picture of a distant subject.
When you take pictures at close range, the resolution of the periphery of the picture may
decrease slightly. This is not a malfunction.
If the lens becomes dirty with fingerprints or dust, the lens may not be able to focus on the
subject correctly.
[PERIPHERAL DEFOCUS]
[FLOWER]

Table of Contents

Other manuals for Panasonic Lumix DMC-GX1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GX1 and is the answer not in the manual?

Panasonic Lumix DMC-GX1 Specifications

General IconGeneral
Megapixel16 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.68 MP
Image sensor size- \
Image formats supportedEXIF, JPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Image stabilizer locationLens
Still image resolution(s)3232x2424, 2272x1704, 1824x1368, 4576x3056, 3232x2160, 2272x1520, 1824x1216, 4576x2576, 3232x1824, 1920x1080, 1824x1024, 3424x3423, 2416x2416, 1712x1712
Filter size52 mm
Digital zoom4 x
Optical zoom- x
Focal length range14 - 42 mm
Lens mount interfaceMicro Four Thirds (MFT)
Maximum aperture number5.6
Minimum aperture number3.5
Number of diaphragm blades7
Number of aspheric elements1
Lens structure (elements/groups)12/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto/Manual
Auto Focus (AF) points23
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance0.2 m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)12800
ISO sensitivity (min)160
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
Shoe mounting point typeHot shoe
Flash exposure correction±2EV (1/3 EV step)
Power source typeBattery
Maximum magnification0.34 x
Video resolutions640 x 480, 720 x 576, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio systemMono
Audio formats supportedAAC, LPCM
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
Magnification0.17 x
USB version2.0
HDMI connector typeMini
Product colorBlack, Silver
Scene modesChildren, Night portrait, Party (indoor), Portrait, Sports, Sunset
Image editingCrop, Resizing, Rotating
Photo effectsSepia
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesMovie, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3
Battery typeH-PS14042
Battery voltage7.2 V
Battery capacity1010 mAh
Battery life (CIPA standard)310 shots
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 7.0 HD Edition\\r SILKYPIX Developer Studio 3.1 SE\\r LoiLoScope
Weight and Dimensions IconWeight and Dimensions
Depth39.4 mm
Width116.3 mm
Height67.8 mm
Weight318 g
Lens length63.6 mm
Lens diameter60.6 mm
Weight (including battery)413 g
