- 211 -
Others
Message Display
Confirmation messages or error messages will be displayed on the screen in some cases.
The major messages are described below as examples.
[THIS PICTURE IS PROTECTED]
> Delete the picture after canceling the protect setting. (P176)
[THIS PICTURE CANNOT BE DELETED]/[SOME PICTURES CANNOT BE DELETED]
This feature can only be used with pictures that comply with the DCF standard.
> If you want to delete some pictures, format the card after saving necessary data on a PC
etc. (P73)
[CANNOT BE SET ON THIS PICTURE]
[TITLE EDIT], [TEXT STAMP] or [PRINT SET] cannot be set for pictures not based on the
DCF standard.
[MEMORY CARD ERROR
FORMAT THIS CARD?]
It is a format that cannot be used with this unit.
> Insert a different card.
> Format the card again with the camera after saving necessary data on a PC etc. (P73)
Data will be deleted.
[LENS NOT FOUND, OR SHOOT W/O LENS IS SET TO OFF.]
When using a Leica lens mount adaptor (DMW-MA2M, DMW-MA3R; optional), set
[SHOOT W/O LENS] (P157) to [ON] in the custom menu.
[THE LENS IS NOT ATTACHED PROPERLY. DO NOT PUSH LENS RELEASE
BUTTON WHILE LENS IS ATTACHED.]
Detach the lens once, and then attach it again without pressing the lens release button. (P15)
Turn on the power again, and if it is still displaying, contact the dealer.
[Lens attachment failed.
Please check connection for dirt.]
Detach the lens from the camera body and gently wipe the contacts on the lens and the
camera body using a dry cotton swab. Attach the lens, turn on the power again, and if it is still
displaying, contact the dealer.
[Lens not detected.
Please turn camera on again.]
This is displayed when the lens has stopped operating normally due to being pressed on by a
hand etc.
> Turn the camera off and on. If the message persists, contact the dealer or your nearest
Service Center.

Table of Contents

Other manuals for Panasonic Lumix DMC-GX1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GX1 and is the answer not in the manual?

Panasonic Lumix DMC-GX1 Specifications

General IconGeneral
Megapixel16 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.68 MP
Image sensor size- \
Image formats supportedEXIF, JPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Image stabilizer locationLens
Still image resolution(s)3232x2424, 2272x1704, 1824x1368, 4576x3056, 3232x2160, 2272x1520, 1824x1216, 4576x2576, 3232x1824, 1920x1080, 1824x1024, 3424x3423, 2416x2416, 1712x1712
Filter size52 mm
Digital zoom4 x
Optical zoom- x
Focal length range14 - 42 mm
Lens mount interfaceMicro Four Thirds (MFT)
Maximum aperture number5.6
Minimum aperture number3.5
Number of diaphragm blades7
Number of aspheric elements1
Lens structure (elements/groups)12/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto/Manual
Auto Focus (AF) points23
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance0.2 m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)12800
ISO sensitivity (min)160
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
Shoe mounting point typeHot shoe
Flash exposure correction±2EV (1/3 EV step)
Power source typeBattery
Maximum magnification0.34 x
Video resolutions640 x 480, 720 x 576, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio systemMono
Audio formats supportedAAC, LPCM
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
Magnification0.17 x
USB version2.0
HDMI connector typeMini
Product colorBlack, Silver
Scene modesChildren, Night portrait, Party (indoor), Portrait, Sports, Sunset
Image editingCrop, Resizing, Rotating
Photo effectsSepia
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesMovie, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3
Battery typeH-PS14042
Battery voltage7.2 V
Battery capacity1010 mAh
Battery life (CIPA standard)310 shots
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 7.0 HD Edition\\r SILKYPIX Developer Studio 3.1 SE\\r LoiLoScope
Weight and Dimensions IconWeight and Dimensions
Depth39.4 mm
Width116.3 mm
Height67.8 mm
Weight318 g
Lens length63.6 mm
Lens diameter60.6 mm
Weight (including battery)413 g
