Panasonic Lumix DMC-GX1 User Manual

Preparation
- 20 -
∫ Battery indication
The battery indication is displayed on the screen.
•
The indication turns red and blinks if the remaining battery power is exhausted. (The status
indicator also blinks) Recharge the battery or replace it with a fully charged battery.
∫ Recording still pictures (when using the LCD monitor/Optional Live Viewfinder
(P196)) (By CIPA standard in Program AE Mode)
Recording conditions by CIPA standard
•
CIPA is an abbreviation of [Camera & Imaging Products Association].
• Temperature: 23 oC (73.4 oF)/Humidity: 50%RH when LCD monitor is on.
• Using a Panasonic SD Memory Card (2 GB).
• Using the supplied battery.
• Starting recording 30 seconds after the camera is turned on.
(When attaching an interchangeable lens compatible with the optical image stabilizer function,
set the optical image stabilizer to [ ])
• Recording once every 30 seconds with full flash every second recording.
• When an interchangeable lens compatible with power zoom (electrically operated zoom) is
attached, the zoom moves from Tele to Wide or from Wide to Tele on each recording.
• Turning the camera off every 10 recordings and leaving it until the temperature of the battery
decreases.
The number of recordable pictures varies depending on the recording interval time.
If the recording interval time becomes longer, the number of recordable pictures
decreases. [For example, if you were to take one picture every two minutes, then the
number of pictures would be reduced to approximately one-quarter of the number
of pictures given above (based upon one picture taken every 30 seconds).]
Approximate operating time and number of recordable pictures
When the interchangeable lens (H-PS14042) is used
Number of recordable pictures Approx. 310 pictures
Recording time Approx. 155 min
When the interchangeable lens (H-FS014042) is used
Number of recordable pictures Approx. 300 pictures
Recording time Approx. 150 min
When the interchangeable lens (H-H014) is used
Number of recordable pictures Approx. 340 pictures
Recording time Approx. 170 min

Panasonic Lumix DMC-GX1 Specifications

General

Megapixel	16 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.68 MP
Image sensor size	- \
Image formats supported	EXIF, JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Lens
Still image resolution(s)	3232x2424, 2272x1704, 1824x1368, 4576x3056, 3232x2160, 2272x1520, 1824x1216, 4576x2576, 3232x1824, 1920x1080, 1824x1024, 3424x3423, 2416x2416, 1712x1712
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 42 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	1
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto/Manual
Auto Focus (AF) points	23
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.2 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±2EV (1/3 EV step)
Power source type	Battery
Maximum magnification	0.34 x
Video resolutions	640 x 480, 720 x 576, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Audio formats supported	AAC, LPCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.17 x
USB version	2.0
HDMI connector type	Mini
Product color	Black, Silver
Scene modes	Children, Night portrait, Party (indoor), Portrait, Sports, Sunset
Image editing	Crop, Resizing, Rotating
Photo effects	Sepia
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Movie, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
Battery type	H-PS14042
Battery voltage	7.2 V
Battery capacity	1010 mAh
Battery life (CIPA standard)	310 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Bundled software	PHOTOfunSTUDIO 7.0 HD Edition\\r SILKYPIX Developer Studio 3.1 SE\\r LoiLoScope

Weight and Dimensions

Depth	39.4 mm
Width	116.3 mm
Height	67.8 mm
Weight	318 g
Lens length	63.6 mm
Lens diameter	60.6 mm
Weight (including battery)	413 g
