27
(ENG) VQT3T96
Easily set a suitable exposure (one push AE)
With one push AE, you can easily achieve a suitable exposure setting when the exposure
setting is too bright or too dark. ( , , modes only)
At purchase, one push AE is assigned to the [Fn1] button.
The exposure meter is displayed, and the aperture and shutter speed are changed to give
a suitable exposure. Which items of the settings change will depend on the Recording
Mode.
Using the function button
The recording functions etc. registered in the [Fn BUTTON
SET] of the [CUSTOM] menu can be assigned to the [Fn1],
[Fn2] (function) buttons, [Fn3] and [Fn4] icon.
You can use the assigned functions by pressing the buttons for
[Fn1] and [Fn2] and by touching the icons for [Fn3] and [Fn4].
To use [Fn2], set the [AF/AE LOCK /Fn2] of the [CUSTOM] menu
to [Fn2].
Select [Fn1], [Fn2], [Fn3] or [Fn4] from the [Fn
BUTTON SET] in the [CUSTOM] menu and
press [MENU/SET].
Select the function you want to assign and
press [MENU/SET].
Assign your favorite function to [Fn1], [Fn2], [Fn3] and [Fn4].
Exit the menu after it is set.
How to tell if the exposure is not adequate
If the aperture values and shutter speed blink red A when the
shutter button is pressed halfway.
If the Manual Exposure Assistance is anything other than
when in mode.
1 Set the [Fn BUTTON SET] of the [CUSTOM] menu to [ONE PUSH AE].
The initial setting for [Fn1] is [ONE PUSH AE].
2 (When exposure is not adequate) Press [Fn1]
A
ョㄏヒ
モョバモユチロヰヤレ
ョㄏビ
ョㄏヒ
DMC-GX1X&GX1K&GX1PP-VQT3T96_eng.book 27 ページ 2011年10月13日 木曜日 午後2時54分

Table of Contents

Other manuals for Panasonic Lumix DMC-GX1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GX1 and is the answer not in the manual?

Panasonic Lumix DMC-GX1 Specifications

General IconGeneral
Megapixel16 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.68 MP
Image sensor size- \
Image formats supportedEXIF, JPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Image stabilizer locationLens
Still image resolution(s)3232x2424, 2272x1704, 1824x1368, 4576x3056, 3232x2160, 2272x1520, 1824x1216, 4576x2576, 3232x1824, 1920x1080, 1824x1024, 3424x3423, 2416x2416, 1712x1712
Filter size52 mm
Digital zoom4 x
Optical zoom- x
Focal length range14 - 42 mm
Lens mount interfaceMicro Four Thirds (MFT)
Maximum aperture number5.6
Minimum aperture number3.5
Number of diaphragm blades7
Number of aspheric elements1
Lens structure (elements/groups)12/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto/Manual
Auto Focus (AF) points23
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance0.2 m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)12800
ISO sensitivity (min)160
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
Shoe mounting point typeHot shoe
Flash exposure correction±2EV (1/3 EV step)
Power source typeBattery
Maximum magnification0.34 x
Video resolutions640 x 480, 720 x 576, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio systemMono
Audio formats supportedAAC, LPCM
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
Magnification0.17 x
USB version2.0
HDMI connector typeMini
Product colorBlack, Silver
Scene modesChildren, Night portrait, Party (indoor), Portrait, Sports, Sunset
Image editingCrop, Resizing, Rotating
Photo effectsSepia
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesMovie, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3
Battery typeH-PS14042
Battery voltage7.2 V
Battery capacity1010 mAh
Battery life (CIPA standard)310 shots
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 7.0 HD Edition\\r SILKYPIX Developer Studio 3.1 SE\\r LoiLoScope
Weight and Dimensions IconWeight and Dimensions
Depth39.4 mm
Width116.3 mm
Height67.8 mm
Weight318 g
Lens length63.6 mm
Lens diameter60.6 mm
Weight (including battery)413 g
