Panasonic Lumix DMC-GX1 User Manual

Others
- 204 -
Cautions for Use
Keep this unit as far away as possible from electromagnetic equipment (such as
microwave ovens, TVs, video games etc.).
•
If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be
disrupted by electromagnetic wave radiation.
• Do not use this unit near cell phones because doing so may result in noise adversely affecting
the pictures and/or sound.
• Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields
created by speakers or large motors.
• Electromagnetic wave radiation generated by microprocessors may adversely affect this unit,
disturbing the pictures and/or sound.
• If this unit is adversely affected by electromagnetic equipment and stops functioning properly,
turn this unit off and remove the battery or disconnect AC adaptor (optional). Then reinsert the
battery or reconnect AC adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
•
If you record near radio transmitters or high-voltage lines, the recorded pictures and/or sound
may be adversely affected.
Always use the supplied cords and cables. If you use optional accessories, use the
cords and the cables supplied with them.
Do not extend the cords or the cables.
Do not spray the camera with insecticides or volatile chemicals.
•
If the camera is sprayed with such chemicals, the body of the camera may be damaged and the
surface finish may peel off.
• Do not keep rubber or plastic products in contact with the camera for a long period of time.
Optimal use of the camera

Panasonic Lumix DMC-GX1 Specifications

General

Megapixel	16 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.68 MP
Image sensor size	- \
Image formats supported	EXIF, JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Lens
Still image resolution(s)	3232x2424, 2272x1704, 1824x1368, 4576x3056, 3232x2160, 2272x1520, 1824x1216, 4576x2576, 3232x1824, 1920x1080, 1824x1024, 3424x3423, 2416x2416, 1712x1712
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 42 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	1
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto/Manual
Auto Focus (AF) points	23
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.2 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±2EV (1/3 EV step)
Power source type	Battery
Maximum magnification	0.34 x
Video resolutions	640 x 480, 720 x 576, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Audio formats supported	AAC, LPCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.17 x
USB version	2.0
HDMI connector type	Mini
Product color	Black, Silver
Scene modes	Children, Night portrait, Party (indoor), Portrait, Sports, Sunset
Image editing	Crop, Resizing, Rotating
Photo effects	Sepia
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Movie, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
Battery type	H-PS14042
Battery voltage	7.2 V
Battery capacity	1010 mAh
Battery life (CIPA standard)	310 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Bundled software	PHOTOfunSTUDIO 7.0 HD Edition\\r SILKYPIX Developer Studio 3.1 SE\\r LoiLoScope

Weight and Dimensions

Depth	39.4 mm
Width	116.3 mm
Height	67.8 mm
Weight	318 g
Lens length	63.6 mm
Lens diameter	60.6 mm
Weight (including battery)	413 g
