Control and monitoring
Control of the vehicles zones depends on the type of connection and system settings.
Type №1. Digital connection – It allows reading information (statuses) and
controlling vehicles (commands) by digital buses of the vehicles. The detailed
information about digital protocols is available on loader.pandorainfo.com. The
declared statuses may not be available for certain vehicle trims.
Type №2. Analog connection – It is a direct connection of analog inputs and
outputs to electrical circuits of a vehicle in accordance with a connection diagram.
Type №3. Built-in sensors – The sensors perform control and protection of the
vehicle. Additional connections are not required
Type №4. Additional sensor (*optional) – External additional sensors are connected
to the base unit (see the System set)
Type Guarded and monitored zones
1 2 3 4
• •
Interior temperature (status)
• •
Engine temperature (status)
• •*
Outside temperature (status)
•
Voltage of the on-board circuits (status, security zone – alarm level)
•
Shock sensor (security zone – alarm and warning level)
•
Motion sensor (security zone – alarm level)
•
Tilt sensor (security zone – alarm level)
• •*
Additional sensor, OE alarm system status via CAN
(status, security zone – alarm and warning level)
