PTS 20-Li A1
GB
│
IE
│
35 ■
Changing the saw blade
WARNING! RISK OF INJURY!
► Always disconnect the battery pack
before carrying out any work on the
appliance.
1. Press the spindle lock
and use the hex key
to loosen the clamping screw (turn clockwise
to open). Now remove the clamping screw
and the clamping flange (see also fig. B).
2. Set the cutting depth to the maximum position.
3. Activate the safety lock-out
and hold it in
position. Swivel the base plate upwards.
4. Remove the saw blade
.
5. Fitting a saw blade is done in the reverse order.
6. Press the spindle lock button
(until it engages)
and use the hex key to tighten the clamping
screw .
■ The arrow on the saw blade must correspond to
the arrow showing the direction of rotation
(running direction shown on the appliance).
Switching the laser on and off
Turn on
♦ Press the Laser ON/OFF switch
.
Switching off
♦ Press the Laser ON/OFF switch
again.
Cleaning and maintenance
WARNING! RISK OF INJURY!
► Always disconnect the battery pack
before carrying out any work on the
appliance.
NOTE
► Have spare parts replaced by the manufac-
turer, their customer service or a similarly
qualified person.
■ Clean the cordless plunge saw after finishing
work.
■ Use a cloth to clean the housing and never use
petrol or detergent.
■ Always keep the area around the blade guard
clean. Remove dust and shavings with a brush.
Disposal
The packaging for this product is made
from environmentally friendly material
and can be disposed of at your local
recycling plant.
Do not dispose of power tools in
your normal domestic waste!
European Directive 2012/19/EU
requires that worn-out power tools
be collected separately and recycled in an environ-
mentally compatible manner.
Your local community or municipal authorities can
provide information on how to dispose of the
worn-out appliance.
WARNING!
► Remove the batteries from the appliance
before disposal.
IB_308629_PTS20-LiA1_LB8.indb 35 13.03.2020 08:37:07
