The sensor for Thermal Mode is in the drive, on top
of the motor. This feature allows you to set a speed
(450 RPM - 3450 RPM) that runs when the IntelliFlo
®
Variable Speed Pump goes into Thermal Mode. The
temperature level that you wish Thermal Mode to start
can also be set.
IMPORTANT NOTE: This feature is for protection of the
pump. Do not depend on the Thermal Mode feature for
freeze protection of the pool. Certain situations could
cause the pump to sense a different temperature than
actual air temperature.
Your automation systems air temperature sensor should
be used to sense actual temperature. For example, if
the pump is located indoors, the temperature of the
room does not indicate the outdoor temperature. The
pump does not sense the water temperature.
THERMAL MODE
Disabled / Enabled - Default: Enabled
DISABLED/ENABLED
SET SPEED
40° F - 50° F (4.4° C - 10° C) Default: 40° F (4.4° C)
PUMP TEMPERATURE
Set Speed (750 RPM - 3450 RPM) Default 1000 RPM
PRIMING
DISABLED/ENABLED
(1 min. to 30 min. hrs.) Default: 11 minutes
MAX PRIMING TIME
Disabled / Enabled - Default: Enabled
Default: Enabled
(1 - 100%) Default: 1
PRIMED SENSITIVITY
(1 second - 10 minutes) Default: 20 seconds
PRIMING DELAY
DISABLED/ENABLED
MENU
Pump Menu: Thermal Mode
To access the Thermal Mode menu:
1. Check that the green power LED is on.
2. Press Menu.
3. Use the Down arrow to scroll to “Thermal Mode”
and press Select.
4. The factory default for Thermal Mode is
“Enabled“. To disable Thermal Mode, press
Select to highlight “Enabled”.
5. Press the Up arrow - “Disabled” is displayed.
6. Press Save to save.
To Set Thermal Mode Speed and Pump Temperature:
Note: Thermal Mode features are only accessible if
Thermal Mode is “Enabled”.
1. With “Thermal Mode” displayed on the screen,
press the Down arrow - “Set Speed” is displayed.
The factory default is 1000 RPM.
2. Press Select to change the speed. The cursor will
highlight the first column (ones).
3. Use the Up or Down arrows to set speed (450 -
3450 RPM).
4. Press Save to save the speed.
5. Press the Down arrow to Pump Temperature (the
temperature the pump will activate Thermal Mode,
default is 40° F/4.4° C).
6. Press Select to change the setting. The cursor will
highlight the first column. Can be set 40° F to 50°
F (4.4° C - 10° C).
7. Press Save to save the temperature setting.
Note: To cancel any changes, press Back to exit
without saving.
8. Press Back to exit.
12:15p
Pump Temperature
40 F
°
ThermMode
Setting the Thermal Mode Pump Temperature
THERMAL MODE
Disabled / Enabled - Default: Enabled
DISABLED/ENABLED
SET SPEED
40° F - 50° F (4.4° C - 10° C) Default: 40° F (4.4° C)
PUMP TEMPERATURE
Set Speed (750 RPM - 3450 RPM) Default 1000 RPM
Thermal Mode Menu Options
12:15pThermMode
Set Speed
1000 RPM
Setting the Thermal Mode Pump Speed
