Technical Data
10
3 Technical Data

3.01 PFAFF 1243
Stitch type: ......................................................................................................... 301 (lockstitch)
Needle system: ................................................................................................................... 134
Model CN8: ....................................................... for the machining of medium-heavy materials
Model C/DN8: ..................... for the machining of medium-heavy materials to heavy materials
Model DN8: .................................................................... for the machining of heavy materials
Needle size in 1/100 mm:
Model CN8: ................................................................................................................. 120 - 150
Model C/DN8: ............................................................................................................. 120 - 190
Model DN8: ................................................................................................................ 160 - 190
Stitch length max: ......................................................................................................... 8.0 mm
Speed max.:
Model CN8 .................................................................................................... 2100 stitches/min
Model C/DN8; DN8 ....................................................................................... 1800 stitches/min
Clearance beneath the roller presser: .............................................................................. 5 mm
Passage width: ............................................................................................................. 270 mm
Clearance height: ......................................................................................................... 115 mm
Bed plate dimensions: .............................................................................................. 518 × 177
Sewing head dimensions:
Length: ............................................................................................................ approx. 530 mm
Width: ............................................................................................................. approx. 177 mm
Height (above table): ....................................................................................... approx. 265 mm
Motor data: ................................................................................. see motor specifi cation plate
Working air pressure ......................................................................................................... 6 bar
Air consumption ...................................................................................... ~0.8 l / working cycle
Noise data:
Emissions sound pressure level in the workplace at n = 1500 min
-1
: ............. L
pA
= 79 dB(A)

(Noise measurement in accordance with DIN 45 635-48-A-1,ISO 11204, ISO 3744, ISO 4871)

Net weight of sewing head: ..................................................................................approx. 42 kg
Gross weight of sewing head: ..............................................................................approx. 50 kg

Subject to alterations.

K
pA
= 2,5 dB
