Set-up
29
Switch off the machine!
Risk of injury due to accidental
machine start-up!
Removing the bobbin case:
 Bring the take-up lever to its top position.
 Open the hook area cover, raise the lever
1 and remove the bobbin case 2.
Inserting the bobbin case:
 Press the bobbin case 2 until you feel it
snap into the bobbin case base.
 Move the lever 1 and close the hook
area cover.
Fig. 9 - 04
9.03 Removing / inserting the bobbin case
1
9.04 Inserting the bobbin case / adjusting the bobbin thread tension
1
2
Fig. 9 - 05
Do not operate the machine with an hook area cover!
Risk of injury due to moving parts!
Switch off the machine!
Risk of injury due to accidental
machine start-up!
 Insert the bobbin as shown in Fig. 9 - 05.
 When the thread is drawn off, the bobbin
must turn in the direction shown by the
arrows.
 Adjust the thread tension by turning the
screw 1.
5 cm
+
-
