Adjustment
11 - 1
11 Adjustment
The illustrations in this section show two-needle machines.
For the
PFAFF 1243PFAFF 1243
PFAFF 1243PFAFF 1243
PFAFF 1243 single-needle machine, various adjustments only have to
be made on one side, i.e. in the right hook compartment.
11.01 Notes on adjusting
All adjustments in these adjustment instructions are based on a completely installed
machine and must only be carried out by appropriately
trained mechanics trained mechanics
trained mechanics trained mechanics
trained mechanics. Covers on the
machine, which have to be removed and replaced for checks and adjustment work, are not
mentioned here.
The screws and nuts in brackets ( ) are for securing of machine parts which are to be
loosened before making the adjustment and tightened again after the adjustment has been
carried out.
11.02 Tools, gauges and other accessories
●Screwdrivers with blade widths from 2 to 10 mm
●Screwdrivers with blade widths from 7 to 14 mm
●Allen keys from 2 to 6 mm
●Metal rule (part No. 08-880 218-00)
●Needle rise gauge (part No. 61-111 600-02)
●Adjustable clamp (part No. 61-111 600-35/001)
●Needles, system 134
●Sewing thread and test material
11.03 Abbreviations
TDC = top dead center
BDC = bottom dead center
