Search Channels
 > OK > OPTIONS > Search channel
You can search for a channel to find it in a long list of
channels. The search will return the matching channel
name with the result arranged in alphabetical order.
1 - Press , to switch to TV.
2 - Long press TV Guide to open the channel
list.
3 - Press OPTIONS > Search channel, and
press OK.
4 - In the typing field, press OK to open on-screen
keyboard, or press Back to hide the on-screen
keyboard.
5 - Use navigation keys to select a character, then
press OK.
- Press (red) key to enter with lower-case
- Press (green) key to enter with upper-case
- Press (yellow) key to enter number and
symbol
- Press (blue) key to delete a character
- Select Enter to start the searching
6 - Select Done when the searching is
completed.
7 - Press Back to close the channel list.
Lock or Unlock Channel
 > OK > OPTIONS > Lock channel, Unlock
channel
To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit Child Lock PIN code first. You
cannot lock programmes from connected devices.
The locked channel will have next to the channel
logo.
Remove Favourite List
 > OK > OPTIONS > Remove favourite list
To remove existing favourite list, select Yes.
7.4
Favourite Channels
About Favourite Channels
You can create a favourite channel list that only holds
the channels you want to watch. With the Favourite
channel list selected, you will only see your favourite
channels when you switch through channels.
Create a Favourites List
1 - While watching a TV channel, long press TV
Guide to open the channel list.
2 - Select the channel, and press Mark as
favourites to mark as favourite.
3 - The selected channel is marked with a .
4 - To finish, press Back . The channels are
added to the Favourites list.
Remove Channel from the Favourites
List
To remove a channel from the favourites list, select
the channel with , then press Unmark as
favourite again to unmark as favourite.
Reorder Channels
You can reorder — reposition — channels in the
Favourite channel list.
1 - While watching a TV channel, press OK >
OPTIONS > Select channel list.
2 - Select Antenna favourite, Cable Favourite or
Satellite favourite*, and press OPTIONS .
3 - Select Reorder channels, select the channel you
want to reorder, and press OK.
4 - Press the Navigation buttons to move the
highlighted channel to another location and
press OK.
5 - Once completed, press Done.
* Satellite channel only can be searched
on xxPxSxxxx TV models.
Favourites List on TV Guide
You can link the TV Guide for your Favourite List.
1 - While watching a TV channel, press OK
> OPTIONS > Select channel list.
2 - Select Antenna favourite, Cable Favourite or
Satellite favourite*, and press OK.
3 - Press TV GUIDE to open it.
With the TV Guide you can view a list of the current
and scheduled TV programmes of your favourite
channels. Along with your favourite channels, the first
3 most used channels from the broadcasters’ default
list will be appended after your favourite channels for
your preview. You need to add these channels into
your favourite list to enable its operation (refer to "TV
Guide" chapter).
On each page of TV Guide, there is a "Did you know"
grid inserted on your favourite channel list. The "Did
24

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PUS7506 and is the answer not in the manual?

Philips 55PUS7506 Specifications

General IconGeneral
Package depth160 mm
Package width1360 mm
Package height840 mm
Package weight17900 g
Noise reduction-
Processor cores2
Teletext standardsHyper-text
Audio formats supportedAAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, HEIF, JPEG, PNG
Video formats supportedAVI, MKV
Video compression formatsAVC, H.264, H.265, HEVC, MPEG1, MPEG2, MPEG4, VP9
Subtitle formats supportedASS, SMI, SRT, SSA, SUB, TXT
High Dynamic Range (HDR) supportedYes
High Dynamic Range (HDR) technologyDolby Vision, Dolby Vision IQ, High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Product colorBlack
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface100 x 200 mm
Cables includedAC
Operating temperature (T-T)5 - 35 °C
Wi-Fi standardsWi-Fi 4 (802.11n)
AC input voltage220-240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.3 W
Power consumption (typical)- W
Audio decodersDolby Atmos
RMS rated power20 W
Programming period8 day(s)
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Video appsNetflix, YouTube
Headphone outputs1
HDMI ports quantity3
Common interface (CI)No
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)EasyLink
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Tuner typeAnalog & digital
Analog signal format systemPAL, SECAM
Digital signal format systemDVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2, DVB-T2 HD
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Display diagonal (metric)139 cm
Harmonized System (HS) code85287280
Repairability index6.3
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)256.2 mm
Width (with stand)1227.7 mm
Height (with stand)742.7 mm
Weight (with stand)13300 g
Depth (without stand)87.1 mm
Height (without stand)712.1 mm
Weight (without stand)13100 g
