Philips 55PUS7506 User Manual

Philips 55PUS7506
67 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #29 background imageLoading...
Page #29 background image
10.4
Videos
Play Videos
To play a video on TV…
Select Videos , and select the file name and
press OK.
• To pause the video, press OK. Press OK again to
continue.
• To rewind or go fast forward, press or . Press
the keys several times to speed up - 2x, 4x, 8x, 16x,
32x.
• To jump to the next video in a folder, press OK to
pause and select on screen and press OK.
• To stop the video playback, press (Stop).
• To go back to the folder, press .
Open video folder
1 - Press SOURCES, select USB and
press OK.
2 - Select USB Flash Drive and press (right)
to select the USB device you need.
3 - Select Videos and select one of video, you
can press OK to play the selected video.
• Select a video and press INFO to show file
information.
• Playback a video and press INFO to show
below:
Progress bar, Playback control bar, (Jump to the
previous video in a folder), (Jump to the next
video in a
folder), (Playback), (Rewind), (Fast
forward), (Pause the playback), (Play all/Play
one), (Shuffle on/Shuffle off)
During the video playback, press OPTIONS to…
Subtitles
Display the subtitles if available, select On, Off,
or On during mute.
Subtitle language
Select subtitles language if available.
Character set
Select the character set if external subtitle is available.
Audio language
Select audio language if available.
Status
Display the information of the video file.
Repeat, Play once
Play videos repeatedly or once.
Subtitle settings
Set the Font size, Subtitle colour, Subtitle position and
Time sync offset if the options are available.
Video Options
When browsing video files, press OPTIONS to…
List/Thumbnails
View video files with list view or thumbnails view.
Subtitles
Display the subtitles if available, select On, Off,
or On during mute.
Shuffle off, Shuffle on
Play videos in sequential order, or at random.
Repeat, Play once
Play videos repeatedly or once.
10.5
Music
Play Music
Open music folder
1 - Press SOURCES, select USB and
press OK.
2 - Select USB Flash Drive and press (right)
to select the USB device you need.
3 - Select Music and select one of music, you
can press OK to play the selected music.
• Select a music and press INFO to show file
information.
• Playback a music and press INFO to show
below:
Progress bar, Playback control bar, (Jump to the
previous music in a folder), (Jump to the next
music in a
folder), (Playback), (Rewind), (Fast
forward), (Pause the playback), (Play all/Play
one)
During the music playback, press OPTIONS to…
Repeat, Play once
Play songs repeatedly or once.
Music Options
When browsing music files, press OPTIONS to…
Shuffle off, Shuffle on
Play songs in sequential order, or at random.
Repeat, Play once
Play songs repeatedly or once.
29

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PUS7506 and is the answer not in the manual?

Philips 55PUS7506 Specifications

General IconGeneral
Package depth160 mm
Package width1360 mm
Package height840 mm
Package weight17900 g
Noise reduction-
Processor cores2
Teletext standardsHyper-text
Audio formats supportedAAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, HEIF, JPEG, PNG
Video formats supportedAVI, MKV
Video compression formatsAVC, H.264, H.265, HEVC, MPEG1, MPEG2, MPEG4, VP9
Subtitle formats supportedASS, SMI, SRT, SSA, SUB, TXT
High Dynamic Range (HDR) supportedYes
High Dynamic Range (HDR) technologyDolby Vision, Dolby Vision IQ, High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Product colorBlack
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface100 x 200 mm
Cables includedAC
Operating temperature (T-T)5 - 35 °C
Wi-Fi standardsWi-Fi 4 (802.11n)
AC input voltage220-240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.3 W
Power consumption (typical)- W
Audio decodersDolby Atmos
RMS rated power20 W
Programming period8 day(s)
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Video appsNetflix, YouTube
Headphone outputs1
HDMI ports quantity3
Common interface (CI)No
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)EasyLink
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Tuner typeAnalog & digital
Analog signal format systemPAL, SECAM
Digital signal format systemDVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2, DVB-T2 HD
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Display diagonal (metric)139 cm
Harmonized System (HS) code85287280
Repairability index6.3
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)256.2 mm
Width (with stand)1227.7 mm
Height (with stand)742.7 mm
Weight (with stand)13300 g
Depth (without stand)87.1 mm
Height (without stand)712.1 mm
Weight (without stand)13100 g
