Philips AJH510 User Manual

8 EN
4 Get started
Always follow the instructions in this chapter in
sequence.
Connect power
Caution
• Risk of product damage! Make sure that the power
voltage corresponds to the voltage printed on the back
or underside of the alarm clock.
• Risk of electric shock! When you unplug the AC
adapter, always pull the plug from the socket. Never
pull the cord.
Note
• The type plate is located on the bottom of the alarm
clock.
Connect the AC adapter to the wall outlet.
Replace battery
Note
• You can only use AC power as power supply. The pre-
installed lithium CR2032 battery can only back up clock
and alarm settings.
• When power is disconnected, the display backlight is off.
When the low battery indicator is displayed,
replace the battery as illustrated.
Tip
• Remove the battery if the alarm clock will not be in use
for a long period of time.
Plug and set
Time has been preset at the factory. When
power is connected, the set time is displayed
automatically.
The built-in lithium battery can maintain clock
setting despite power interruption.
Select time zone
If the hour digits of the preset time do not
match your local time, you need adjust the time
zone settings.
1 In standby mode, press TIME ZONE.
» The current time zone number blinks
on the display panel.
2 Rotate VOLUME +/- to select time zone
(-10 to -4 adjustable).
3 Press TIME ZONEtoconrmthesetting.

Philips AJH510 Specifications

General

AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Number of batteries supported	1
Snooze function	Yes
Package weight	730 g
RMS rated power	0.6 W
Display type	LED

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	144 x 65 x 144 mm
