Philips DCM250 User Manual

20 EN
the video input jacks on the TV.•
2 Ensure that the iPod/iPhone is loaded
correctly.
3 Press iPod to select the iPod/iPhone
source.
4 Press MENU to enter the iPod/iPhone
menu.
5 Press to select a video fi le.
6 Press OK to confi rm.
Charge the iPod/iPhone
When the DCM250 is connected to power, the
docked iPod/iPhone begins to charge.
Remove the iPod/iPhone
1 Pull the iPod/iPhone out of the dock.
PbPr Y

Philips DCM250 Specifications

Sound

output power (RMS)	2x15 W
sound system	Stereo
loudspeaker types	Bass Reflex Speaker System

Tuner/Reception/Transmission

tuner bands	FM, MW
station presets	40
antenna	FM Antenna

Connectivity

usb	USB host
aux in	Yes
headphone	3.5 mm

Dimensions

product width	390 mm
product height	140.5 mm
product depth	200.5 mm
