6 7
1.Use proper installation kit according to the door thickness.
2.The default installation kit is applicable to doors of 38-60mm thickness.
If the thickness of your door is not within this range, please contact us.
Step 3 | Choose the directional screw
Change the direction of the directional screw.
Two-way
latch bolt
Directional
screw
Directional
screw
āAdjust the direction of the
directional screw according
to the door opening direction
(the directional screw must be
mounted on the inside of the door,
namely the inside escutcheon).
Please make sure
the main dead bolt
is retracted during
installation.
Please install square shafts
and connecting screw tubes
with proper length.
2
Pass the connection wire through
the top hole. Meanwhile, align
the cylinder key tailpiece and
square shaft with the 2 rotary
holes on the mortise, and insert
them to make sure the outside
escutcheon is kept close to the
outside of the door.
Tighten the mounting plate with
the 4 M5 chamfer head screws
against the inside of the door.
4
5
Installation steps
3
1
Use the drilling
template to drill
the needed holes
on the door and
mount the mortise
into the door.
Tighten the 4
anchor screws
on the mortise.
Install the connecting screw
tube and anchor screw tube
on the outside escutcheon.
Place the square shaft and
compressed spring into the
hole of the handle.
The following installation steps apply to right-open doors. For left-open doors,
please read the chapter [Pre-installation instructions] carefully and make
needed adjustments.
Attention
Attention Attention
M5 screw tube
M6 screw tube
Cylinder key tailpiece
Press the thicker end of
the compressed spring
towards the handle
To Next Page
