IBSL SYS PRO UM E
1-42 6057AC01
Supply Voltage (U
S
)
Nominal value U
S
= 24 V DC
Ripple U
PP
= 3.6 V within the permissible voltage range
Permissible voltage range 20 V DC to 30 V DC, ripple included
Overvoltage protection 35 V (for 0.5 s)
Connection Type
Remote bus connection (BK module) – Fiber optic: Bus connection with F-SMA
connectors
– Copper: MINI-COMBICON connector
Installation local bus connection (BK module -
installation local bus)
– COMBICON connector 1.5 mm² [16 AWG]
(IP 20)
– QUICKON connection method, PG 11
threaded joint (IP 65)
Bus connection (installation local bus -
installation local bus)
– QUICKON connection method 2 x 1.5 mm²
[16 AWG], PG11-threaded joint (IP 65)
I/O connection
(installation local bus - I/O)
– 5-pos. M12 connectors
– Actuator supply: QUICKON connection
method 3 x 1.5 mm² [16 AWG] (24 V, GND,
PE), PG13,5-threaded joint (IP 65)
Data Interface to Installation Local Bus
Cable lengths Max. cable length between two devices:
10 m (32.808 ft.)
Max. total length of the installation local bus:
100 m (328.084 ft.)
Error evaluation Diagnostic and status indicators
Electrical isolation Module-specific
INTERBUS Loop System Basic Specifications
Transmission medium Unshielded, two-wire cable, 2 x 1.5 mm²
[16 AWG]
Maximum number of devices 32
Signal coding Manchester code
