Removal
To remove the front fork, first remove:
- the front wheel.
- the brake calliper.
- the handlebar.
- Unscrew the upper ring nut, using the specific
tool.
Specific tooling
020055Y Wrench for steering tube ring nut
- Extract the upper ring nut.
- Extract the safety washer.
Suspensions NRG 50
SUSP - 174
