- Disconnect the electrical connections.
-First loosen the screw coupling the hydraulic hose
of the front braking system.
- Unscrew and remove the screws of the U-bolt
fastening the front brake pump to the handlebar.
- Unscrew and remove the coupling screw of the
front brake pipe.
In this way the brake pump can be removed.
Braking system NRG 50
BRAK SYS - 210
