- Unscrew and remove the screws fastening the
radiator to the upper and lower bracket.
- Remove the radiator.
RADIATOR - FITTING
Fit the radiator.
- Insert and tighten the screws fastening the radi-
ator to the upper and lower bracket.
NRG 50 Cooling system
COOL SYS - 217
