PIAGGIO X8 200 User Manual

03_10
03_11
03_12
6. Loosen the two screws "G" and hence remove the fairing mid-joining segment (de-
taching the license plate lamp connector), in order to allow for the removal of the
underlying fixings "H".
The figure shows the removal of the LHS fairing; the RHS may be removed following
the same procedure.
46
3 Maintenance

PIAGGIO X8 200 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	198 cc
Cooling System	Liquid cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Front Suspension	Telescopic hydraulic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	120/70-14
Fuel Capacity	12 liters
Seat Height	790 mm
Max Torque	17 Nm
Rear Suspension	Dual shock absorbers
