Fuel tank
FUEL TANK
Code
Action
Duration
1
004168
Fuel tank cap - Replacement
2
005010
Tank float - Replacement
3
004112
Cock-carburettor hose - Replace-
ment
4
004005
Fuel tank - Replacement
5
004007
Fuel valve - Replacement
6
004109
Fuel tank breather - change
MSS ZIP 100 4T
Time
TIME - 173
172
174
