Handlebar covers
HANDLEBAR COVERS
Code
Action
Duration
1
004019
Handlebar rear section - Replace-
ment
2
004018
Handlebar front section - Replace-
ment
3
005078
Odometer glass - Replacement
4
005076
Clock / Cell - Replacement
5
005014
Odometer - Replacement
6
005038
Instrument panel warning light bulbs
- Replacement
Time
MSS ZIP 100 4T
TIME - 176
175
177
