3.3 JIGS LIST
3.4 CLEANING
- Jigs List
- Grease List
Name
16P FFC
Test Disc
L.P.F.
Acetate Tape
Jig No.
GGD1310
TCD-782
GYH1026
Remarks
Tuner Amp Unit - CD Core Unit
Checking the grating
Checking the grating (Two pieces)
Capacitor Bond Lock
Name
Grease
Grease
Grease
Silicon Glue
Grease No.
GEM1024
GEM1043
GEM1013
GEM1017
Remarks
CD Mechanism Module
CD Mechanism Module
Panel Assy
Capacitor Bond Lock
N
ame
G
rease No.
R
emar
k
s
Before shipping out the product, be sure to clean the
following portions by using the prescribed cleaning
tools:
Portions to be cleaned Cleaning tools
CD pickup lenses Cleaning liquid : GEM1004
Cleaning paper : GED-008

Pioneer DEH-80PRS Series Specifications

General

Channels	4
Preamp Outputs	6-channel
Preamp Voltage	5 volts
Subwoofer Output	Yes
Bluetooth	No
Auxiliary Input	Front
CD Playback	Yes
DIN Size	Single DIN
CEA-2006 Compliant	Yes
Display Type	LCD
MP3 Playback	Yes
WMA Playback	Yes
AAC Playback	Yes
FLAC Playback	Yes
HD Radio	No
Remote Control	Yes
Built-in DSP	Yes
Built-in Parametric EQ	Yes
Time Alignment	Yes
MOSFET Power Supply	Yes
High-Voltage Preamp Output	Yes
Digital Time Correction	Yes
Auto EQ	Yes
Advanced Sound Retriever	Yes
Dual Zone	No
iPod/iPhone Control	Yes
Detachable Faceplate	Yes
Power Output	50 Watts x 4 Channels
RMS Power Output	14 Watts x 4 Channels
Peak Power Output	50 watts
USB Input	Front
Display	LCD
SIRIUS or XM Radio Ready	Yes
Equalizer	16-Band Graphic Equalizer
