11.3 CD CORE UNIT (S11.6STD)
C
SIDE A
C
CD CORE UNIT (S11.6STD)
R232
C201
C205
TH201
R245
R246
R253
R254
C220
R264
C235
C238
C240
R297
C299
R301
R302
R303
R304
R305
R306
R307
R308
R309
15 10 5 1
CN101
R701
R702
R706
R710
C102
15 10 5 1
CN701
1 5
10
CN702
C306
C307
C308
C312
C701
C702
C705
C707
C710
1
S901
D101
10 5 1
15 20 25
IC301
R201
R202
10 20 30 40 50
X
60
50
40
30
20
10
0
Y
M1
SPINDLE
MOTOR
M2
LOADING/CARRIAGE
MOTOR
A
CN461
PICK UP UNIT(P10.6) (SERVICE)
HOME
REFO1
F
E

Pioneer DEH-80PRS Series Specifications

General

Channels	4
Preamp Outputs	6-channel
Preamp Voltage	5 volts
Subwoofer Output	Yes
Bluetooth	No
Auxiliary Input	Front
CD Playback	Yes
DIN Size	Single DIN
CEA-2006 Compliant	Yes
Display Type	LCD
MP3 Playback	Yes
WMA Playback	Yes
AAC Playback	Yes
FLAC Playback	Yes
HD Radio	No
Remote Control	Yes
Built-in DSP	Yes
Built-in Parametric EQ	Yes
Time Alignment	Yes
MOSFET Power Supply	Yes
High-Voltage Preamp Output	Yes
Digital Time Correction	Yes
Auto EQ	Yes
Advanced Sound Retriever	Yes
Dual Zone	No
iPod/iPhone Control	Yes
Detachable Faceplate	Yes
Power Output	50 Watts x 4 Channels
RMS Power Output	14 Watts x 4 Channels
Peak Power Output	50 watts
USB Input	Front
Display	LCD
SIRIUS or XM Radio Ready	Yes
Equalizer	16-Band Graphic Equalizer
