Pioneer DEH-80PRS Series User Manual

DEH-80PRS/XNUC
36
1234
1234
C
D
F
A
B
E
8.3 PCL OUTPUT CONFIRMATION
- PCL Output
In the normal operation mode (with the detachable panel installed, the ACC switched ON, the standby mode
cancelled), shift the TEST_IN IC601 (Pin 61) terminal(TP : TESTIN1) to H.
The clock signal is output from the PCL terminal IC601 (Pin 37)(TP : PCL).
The frequency of the clock signal is 625.0 kHz that is one 32th of the fundamental frequency (20 MHz).
If the clock signal out of the range, the X’tal (X601) should be replaced with new one.

Pioneer DEH-80PRS Series Specifications

General

Channels	4
Preamp Outputs	6-channel
Preamp Voltage	5 volts
Subwoofer Output	Yes
Bluetooth	No
Auxiliary Input	Front
CD Playback	Yes
DIN Size	Single DIN
CEA-2006 Compliant	Yes
Display Type	LCD
MP3 Playback	Yes
WMA Playback	Yes
AAC Playback	Yes
FLAC Playback	Yes
HD Radio	No
Remote Control	Yes
Built-in DSP	Yes
Built-in Parametric EQ	Yes
Time Alignment	Yes
MOSFET Power Supply	Yes
High-Voltage Preamp Output	Yes
Digital Time Correction	Yes
Auto EQ	Yes
Advanced Sound Retriever	Yes
Dual Zone	No
iPod/iPhone Control	Yes
Detachable Faceplate	Yes
Power Output	50 Watts x 4 Channels
RMS Power Output	14 Watts x 4 Channels
Peak Power Output	50 watts
USB Input	Front
Display	LCD
SIRIUS or XM Radio Ready	Yes
Equalizer	16-Band Graphic Equalizer
